BEI-C Multifunctional Diesel System Tester for Common Rail Injector, Pump, and EUI/EUP Coding

BEI-C Multifunctional Diesel System Tester for Common Rail Injector, Pump, and EUI/EUP Coding

The BEI-C is an all-in-one professional diagnostic solution designed for the modern diesel service center. It offers comprehensive testing for solenoid and piezo injectors from world-leading brands like Bosch, Delphi, Denso, Siemens, Caterpillar, and Cummins. Its versatility extends to testing high-pressure common rail pumps, HEUI systems, and specialized pumps like VP37, VP44, and RED4.

This tester stands out for its high-precision injector coding capabilities (including Bosch IQA/IMA, Denso QR, and Delphi I2C/I3C) and its ability to test complex EUI/EUP systems such as Delphi E3 and Cummins M11 double-solenoid units. Built to meet original factory standards, the BEI-C ensures every diagnostic result is accurate and reliable, supported by a fully open and updatable database.

• Universal Component Support: Tests injectors and pumps from Bosch, Delphi, Denso, Siemens, CAT, Cummins, and more.

• Advanced Injector Coding: Generates precision codes including Bosch IMA/ISA, Denso 16-32QR, Delphi I2C/I3C, and Siemens IIC.

• Comprehensive EUI/EUP Testing: Specialized support for double-solenoid EUI (Delphi E3) and double-pulse EUI (Cummins M11 Celect).

• Extended System Diagnostics: Optional modules for HEUI injectors/pumps, CAT 320D pumps, VP37/VP44 pumps, and Cummins HPI/PT systems.

• Clinical Measurement Accuracy: Features specialized tests for Response Time (BIP), Armature Lift (AHE), Resistance, and Inductance.

• Open Database: The part number database is fully open, allowing users to add and customize test plans as needed.

• Flexible Integration: Can be connected to traditional mechanical pump test benches and measuring cups for volume analysis.
