CR304(S) High Pressure Common Rail Injector Test Bench

The CR304(S) is a professional, industrial-grade common rail injector test bench engineered to accurately imitate the real-world operating conditions of a diesel engine ECU (Engine Control Unit). It provides highly precise common rail system control signals to drive and calibrate high-pressure injectors, making it an essential diagnostic platform for advanced diesel service shops, commercial fleet garages, and fuel system rebuilding centers.

This equipment features an intelligent automated control system that allows technicians to flexibly set, adjust, and save drive signal parameters according to actual workshop requirements. By delivering precise execution across multiple test steps, the CR304(S) provides an efficient and definitive diagnostic solution to judge, repair, and balance the delivery performance of mainstream global fuel systems.

Common Rail Injector Test Bench, Diesel Injector Tester, Piezo Injector Testing

Compatible Common Rail Injector Brands

OEM Reference	Injector Family	Typical Vehicle
0445110 series	Bosch CP1 / CP3 solenoid	Mercedes A-Class, VW Golf, Hyundai H-1
0445116 series	Bosch CRI2-16 solenoid	BMW 320d, Volvo V50, Renault Laguna
0445117 series	Bosch CRI2-16 Piezo	Audi A4, Mercedes E-Class, VW Touareg
095000-0760	Denso ECD-U2P	Toyota Hilux, Mitsubishi Triton
EJBR01501Z	Delphi EUI	Land Rover Defender, Ford Transit
A2C59511601 / 5WS40539	Siemens Continental piezo	Ford Transit, Peugeot 308, Citroën C4

ECU Simulation Coverage and Applications

The industrial-grade test bench imitates real-world ECU (Engine Control Unit) operating conditions to provide highly precise common rail system control signals. The intelligent automated control system allows technicians to flexibly set, adjust and save drive signal parameters according to actual workshop requirements. Across multiple test steps, the platform delivers precise execution to judge, repair and balance the delivery performance of mainstream global fuel systems for advanced diesel service shops, commercial fleet garages and fuel system rebuilding centers.

Frequently Asked Questions

Q1. What does the ECU simulation do?
It imitates real-world ECU operating conditions to deliver highly precise common rail system control signals for accurate injector calibration.

Q2. Can drive signal parameters be customized?
Yes. The intelligent automated control system allows technicians to flexibly set, adjust and save drive signal parameters according to workshop requirements.

Q3. Which injector families are supported?
Bosch, Denso, Delphi and Siemens injectors are supported through the integrated driver module.

Q4. Is it suitable for commercial fleet garages?
Yes. The platform is designed for advanced diesel service shops, commercial fleet garages and fuel system rebuilding centers.

Q5. Can it test solenoid and piezo injectors?
Yes. Both solenoid and piezo injector families are supported on the same test platform.

CR304(S) High Pressure Common Rail Injector Test Bench Advantage

Advanced ECU Simulation: Flawlessly replicates real-world diesel engine ECU signals to drive high-pressure injectors with maximum accuracy.
Comprehensive System Compatibility: Fully supports testing and diagnostics for standard common rail solenoid and advanced piezoelectric ceramic injectors from Bosch, Denso, Delphi, and more.
Flexible Parameter Customization: Allows operators to customize, fine-tune, and save specific drive signal characteristics to easily match unique field-testing requirements.
Dual Testing Modes: Features both standard thorough diagnostics and a dedicated quick-test mode (20 seconds per condition) to drastically enhance workshop throughput.
Automated Report Generation: Automatically sequence through preset operational conditions and outputs comprehensive, easy-to-read calibration reports upon completion.
Rugged Heavy-Duty Structure: Built with a massive 350kg high-rigidity frame to absorb high-pressure harmonics and ensure maximum testing stability.

Remote Diagnostics Support: Online remote assistance is available for installation, calibration and software upgrades.
12 Months Warranty: Full machine warranty covers spare parts and remote support for one year after delivery.

parameter

Technical Feature	Specifications / Details
Model	CR304(S)
Nominal Power of Main Engine	5.5 kW
Overall Size (LWH)	160 x 100 x 180 cm
Machine Weight	350 kg
Operating Temperature Range	-10 ℃ to 50 ℃ (14 ℉ to 122 ℉)
Non-Operating Storage Temp	-20 ℃ to 70 ℃ (-4 ℉ to 158 ℉)
Relative Humidity (Operating)	15% to 95% at 40 ℃ (Non-condensing)
Compatible Injector Technologies	High-Pressure Solenoid Injectors, Piezoelectric Ceramics (Bosch, Denso, Delphi, etc.)
Control Features	Soft Keyboard, Custom Steps Editing, Interactive Diagnostic Database
